Xerox WorkCentre 5945 Service Manual

February 2016
5-97
Xerox® WorkCentre® 5945 Family
Common Hardware
Parts Lists
Common Hardware
Item Part Description
A
– Screw M3x6 Taptite (Zinc finish)
B – Screw M4x8 Taptite
C – Screw M4x12 Self Tapping
D – Screw M3.9.5 Taptite
E – Screw M3x8 Taptite
F – Screw M3x7.5 Taptite
G – Screw M4x12 Self Tapping
H – Screw M3x4.5 Machine
I – Screw M4x16 Self Tapping
J – Screw M3x14 Self Tapping (Countersunk)
K – Screw M3x16 Self Tapping
L – Screw M4x10 Self Tapping
M – E-Clip M4
N – E-Clip M5
O – Screw M4x12 Self Tapping
P – Screw M4x12 Taptite
Q – Screw M4x11 Self Tapping
R – KL Clip M6
S – Screw M4x30 Taptite
T – Screw M3x10 Self Tapping
U – Screw M3x10 Taptite
V – Screw M3x6 Taptite
W – Screw M3x16 Self Tapping
X – Screw M3x6 Self Tapping
Y – E-Clip M8
Z – E-Clip M4
AA – E-Clip M7
AB – Screw M3x25 Self Tapping
AC – Screw M3x4 Taptite
AD – E-Clip M6
AE – Washer M8
AF – Spring Washer M6
AG – Screw M3.5x10 Self Tapping
AH – Circlip M5
AI – Circlip M8
AJ – Star Washer M4
AK – Screw M4x9.5 Machine
AL – Screw M5x18 Self Tapping
AM – Star Washer M3.5
AN – Screw M3.5x5.5 Machine
AO – Screw M3.5x6 Machine
AP – Screw M5x11 Taptite
AQ – Screw M3x8 Taptite
AR – Screw M4x8 Machine
AS – Screw M4x10 Self Tapping
AT – Screw M4x10 Self Tapping
AU – Screw M3x5 Machine
AV – E-Clip M3.5
AW – Screw M3x5.5 Taptite
AX – Screw M3x14 Machine
AY – Screw M3x18 Self Tapping
AZ – Washer M4
BA – Screw M4x16 Machine
BB – Screw M4x5 Machine
BC – Screw M3x10 Machine
BD – Screw M3x6 Machine
BE – Screw M4x7.5 Machine
BF – Screw M3x5.5 Machine
BG – Washer M3
BH – Spring Washer M3
BI – Screw M3x6 Machine
BJ – Screw M3x22 Self Tapping
BK – Retaining Ring (Skiffy) M7
BL – Circlip M10
BM – Screw M3x8 Machine
BN – Screw M4x8 Self Tapping
BO – Screw M3x6 Taptite
BP – Screw M3x4 Machine (Countersunk)
BQ – Screw M3x16 Machine
BR – Screw M3x9.5 Self Tapping
BT – Screw M4x8 Self Tapping
BU – Screw M3x5.5 Self Tapping
BV – Screw M4x7 Taptite
BW – Screw M3x6 Self Tapping
BX – Screw M3x8 Self Tapping
BY – Screw M4x8 Self Tapping
BZ – Screw M4x16 Taptite
CA – Screw M3x8 Self Tapping
CB – Screw M4x10 Self Tapping
CC – Screw M4x8 Self Tapping
CD – Screw M3x10 Self Tapping
CE – Screw M3x12 Self Tapping
CF – Screw M4x5 Taptite
CG – Circlip M6
CH – Screw M3x10 Machine
CI – Screw M4x5 Machine
CJ – Screw M3x11 Self Tapping
CK – E-clip M2.5
CL – Washer M5
CM – Screw M4x9 Self Tapping
CN – Screw M3x14 Self Tapping
CO – Screw M3x8 Self Tapping
CP – Screw M4x15 Taptite
CQ – Spring Washer M8
CR – Screw M3x8 Self Tapping
CS – Screw M4x8 Machine
CT – Screw M3x5.5 Machine
CU – Screw M3x9 Self Tapping
CV – Nut M3
CW – Nut M3
CX – Screw M4x6 Machine
www MK-Electronic de

Xerox WorkCentre 5945 Specifications

General

Print Technology	Laser
Print Speed	Up to 45 ppm
Maximum Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Maximum Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan, Fax
Copy Speed	Up to 45 cpm
Copy Resolution	600 x 600 dpi
Processor	1.2 GHz Dual-core
Memory	2 GB
Fax	Optional
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Connectivity	USB, Ethernet
Paper Size	A4, A5
PDL	PCL6, PDF, XPS, TIFF, JPEG
Mobile Printing	Apple AirPrint
Dimensions	640 x 700 x 1140 mm
Scanner Type	ADF, Flatbed
Weight	Approx. 172.0 lb / 78 kg
