Xerox WorkCentre 5945

February 2016
5-57
Xerox® WorkCentre® 5945 Family
PL 12.420
Parts Lists
PL 12.420 LVF BM Crease Roll
A
ssembly (3 of 3)
Item Part Description
1
031K09230 Bail arm assembly (REP 12.29-
150)
2 050E29400 Bin 2
3 032K10330 Exit upper guide assembly (REP
12.28-150)
4 – Exit lower guide (Not Spared)
5 – Bail arm support bracket (P/O PL
12.420 Item 1)
6 – Bail arm pin (P/O PL 12.420 Item 1)
7 130E10360 Bin 2 90% full sensor (Q12-206)
(REP 12.29-150)
8 868E93710 BM exit sensor (Q12-213) (REP
12.28-150)
9 – Static eliminator (P/O PL 12.420
Item 3)
10 899E07770 Bail arm spring (REP 12.29-150)
11 059E11880 Bail arm roller (x2) (REP 12.29-
150)
