FEATURES
1-11
Meter displays during cruise control system operation
Self-diagnosis device
The cruise control system will also become deactivated when an irregularity with any of the vehicle sys-
tems is detected. The cruise control setting indicator light “SET” will go off and the cruise control system
indicator light “ ” will flash. You will not be able to use the cruise control system while the engine trou-
ble warning light is on, or while the cruise control system is malfunctioning.
NOTICE
ECA1MC1006
If the display indicates a fault code, the vehicle should be checked as soon as possible in order
to avoid engine damage.
C
D
B
A
d
c
b
aa
A. Cruise control system is activated (cruising
speed is set)
B. Cruise control system is turned off (cruise
control system indicator light “ ”
flashes)
C. Cruise control system is turned off
D. Cruise control system is turned on (cruising
speed is not set)
a. Condition for automatically deactivating cruise
control system is detected
b. 4 seconds elapse (during this time, input from
the cruise control power switch “ ” will not be
received)
c. Cruise control power switch “ ” “ON”
d. Cruising speed is set
GEAR
N
25
A.TEMP ˚C
Lo
C.TEMP ˚C
0:06
TIME TRIP
1 2 3 4
1. Engine trouble warning light “ ”
2. Cruise control system indicator light “ ”
3. Cruise control setting indicator light “SET”
4. Fault code display
