ELECTRICAL SPECIFICATIONS
2-13
EAS20310
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system TCI
Ignition timing (B.T.D.C.) 5.0°/1050 r/min
Engine control unit
Model/manufacturer TBDFE3/DENSO (Europe except (F)) (AUS)
TBDFH3/DENSO (B) (F)
Ignition coil
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 1.19–1.61 Ω
Secondary coil resistance 8.50–11.50 kΩ
AC magneto
Standard output 14.0 V, 590 W at 5000 r/min
Stator coil resistance 0.128–0.192 Ω
Voltage regulator
Rectifier/regulator
Regulator type Semi conductor-short circuit
Regulated voltage (DC) 14.3–14.7 V
Rectifier capacity (DC) 50.0 A
Withstand voltage 40.0 V
Battery
Model GT14B-4
Voltage, capacity 12 V, 12.0 Ah
Manufacturer GS YUASA
Ten hour rate amperage 1.20 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60.0 W/55.0 W × 2
Auxiliary light LED
Tail/brake light 12 V, 5.0 W/21.0 W × 2
Front turn signal light LED
Rear turn signal light 12 V, 21.0 W × 2
License plate light 12 V, 5.0 W × 1
Meter lighting LED
Indicator light
Neutral indicator light LED
Turn signal indicator light LED
Oil level warning light LED
High beam indicator light LED
