CHASSIS SPECIFICATIONS
2-12
Spring stroke K1 0.0–67.5 mm (0.00–2.66 in)
Spring stroke K2 67.5–135.0 mm (2.66–5.31 in)
Inner tube outer diameter 48.0 mm (1.89 in)
Inner tube bending limit 0.2 mm (0.01 in)
Optional spring available No
Recommended oil Suspension oil M1 or equivalent
Quantity 716.0 cm³ (24.21 US oz, 25.20 Imp.oz) (left side)
694.0 cm³ (23.46 US oz, 24.43 Imp.oz) (right
side)
Level 106.0 mm (4.17 in) (left side)
90.0 mm (3.54 in) (right side)
Spring preload adjusting positions
Minimum (soft) 15.0 mm (0.59 in)
Standard 10.0 mm (0.39 in)
Maximum (hard) 0 mm (0 in)
Rebound damping adjusting positions
Minimum 16 clicks out
Standard 12 clicks out
Maximum 1 click out
Compression damping adjusting positions
Minimum 21 clicks out
Standard 11 clicks out
Maximum 1 click out
Rear suspension
Type Swingarm (link suspension)
Spring/shock absorber type Coil spring/gas-oil damper
Rear shock absorber assembly travel 60.0 mm (2.36 in)
Spring free length 157.6 mm (6.20 in)
Spring installed length 145.9 mm (5.74 in)
Spring free length 67.8 mm (2.67 in)
Spring installed length 62.0 mm (1.26 in)
Soft
Spring rate K1 171.00 N/mm (17.44 kgf/mm, 976.41 lbf/in)
Spring rate K2 342.00 N/mm (34.87 kgf/mm, 1952.82 lbf/in)
Spring stroke K1 0.0–42.0 mm (0.00–1.65 in)
Spring stroke K2 42.0–60.0 mm (1.65–2.36 in)
Hard
Spring rate K1 171.00 N/mm (17.44 kgf/mm, 976.41 lbf/in)
Spring stroke K1 14.1–60.0 mm (0.56–2.36 in)
Optional spring available No
Enclosed gas/air pressure (STD) 1200 kPa (12.0 kgf/cm², 170.7 psi)
Spring preload adjusting positions
Rider only SOFT
With passenger or cargo HARD
Rebound damping adjusting positions
Minimum 20 clicks out
Standard 12 clicks out
Maximum 3 clicks out
