Yamaha FJR1300A(D) - Rear Brake

REAR BRAKE
4-50
EAS22550
REAR BRAKE
Removing the rear brake pads
Order Job/Parts to remove Q’ty Remarks
1 Rear brake caliper bolt 2
2 Rear brake caliper 1
3 Brake pad shim 2
4 Rear brake pad 2
5 Brake pad spring 2
For installation, reverse the removal proce-
dure.
