Yamaha FJR1300A(D) - Chassis Tightening Torques

TIGHTENING TORQUES
2-22
EAS20350
CHASSIS TIGHTENING TORQUES
Item
Thread
size
Q’ty Tightening torque Remarks
Engine mounting bolt (right front
lower side)
M12 1 49 Nm (4.9 m·kg, 35 ft·lb)
Engine mounting bolt (right front
upper side)
M12 1 49 Nm (4.9 m·kg, 35 ft·lb)
Engine mounting bolt (left front
lower side)
M12 1 49 Nm (4.9 m·kg, 35 ft·lb)
Engine mounting bolt (left front
upper side)
M12 1 49 Nm (4.9 m·kg, 35 ft·lb)
Engine mounting nut (rear upper
side)
M10 1 45 Nm (4.5 m·kg, 32 ft·lb)
Spacer bolt M16 1 18 Nm (1.8 m·kg, 13 ft·lb)
Engine mounting bolt (rear lower
side)
M10 1 45 Nm (4.5 m·kg, 32 ft·lb)
Engine bracket and engine bolt
(left rear side)
M8 2 16 Nm (1.6 m·kg, 11 ft·lb)
Engine bracket and frame bolt
(left rear side)
M10 1 32 Nm (3.2 m·kg, 23 ft·lb)
Engine bracket bolt (top) M8 4 16 Nm (1.6 m·kg, 11 ft·lb)
Engine bracket and engine bolt
(top)
M10 2 37 Nm (3.7 m·kg, 27 ft·lb)
Pinch bolt (front side) M8 2 24 Nm (2.4 m·kg, 17 ft·lb)
Pinch bolt (rear lower side) M8 2 24 Nm (2.4 m·kg, 17 ft·lb)
Main frame and rear frame bolt
(upper side)
M8 4 28 Nm (2.8 m·kg, 20 ft·lb)
Main frame and rear frame bolt
(lower side)
M10 2 48 Nm (4.8 m·kg, 35 ft·lb)
Rear frame and hydraulic unit
bracket bolt
M6 4 11 Nm (1.1 m·kg, 8.0 ft·lb)
Pivot shaft M28 1 23 Nm (2.3 m·kg, 17 ft·lb)
Pivot shaft self-lock nut (right
side)
M18 1 125 Nm (12.5 m·kg, 90 ft·lb)
Pivot shaft nut (left side) M28 1 115 Nm (11.5 m·kg, 85 ft·lb)
Pivot shaft nut retainer bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Relay arm and frame nut M10 1 40 Nm (4.0 m·kg, 29 ft·lb)
Connecting arm and relay arm
nut
M10 1 48 Nm (4.8 m·kg, 35 ft·lb)
Connecting arm and swingarm
nut
M10 1 48 Nm (4.8 m·kg, 35 ft·lb)
Rear shock absorber assembly
upper nut
M12 1 64 Nm (6.4 m·kg, 46 ft·lb)
Rear shock absorber assembly
lower nut
M10 1 40 Nm (4.0 m·kg, 29 ft·lb)
E
E
LT
LT
LS
