TIGHTENING TORQUES
2-23
Rear shock absorber spring pre-
load adjusting lever nut
M6 3 7 Nm (0.7 m·kg, 5.1 ft·lb)
Upper bracket pinch bolt M8 2 26 Nm (2.6 m·kg, 19 ft·lb)
Lower bracket pinch bolt M8 4 23 Nm (2.3 m·kg, 17 ft·lb)
Steering stem nut M28 1 115 Nm (11.5 m·kg, 85 ft·lb)
Lower ring nut M30 1 See TIP.
Immobilizer unit coupler cover
holder bolt
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Handlebar bolt M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Handlebar nut M12 2 65 Nm (6.5 m·kg, 47 ft·lb)
Clutch master cylinder holder bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Front brake master cylinder hold-
er bolt
M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Front fork cap bolt locknut (right
front fork leg)
M10 1 14 Nm (1.4 m·kg, 10 ft·lb)
Front fork damper rod assembly
bolt
M10 2 35 Nm (3.5 m·kg, 25 ft·lb)
Front fork cap bolt M45 2 25 Nm (2.5 m·kg, 18 ft·lb)
Front fender bolt M6 4 6 Nm (0.6 m·kg, 4.3 ft·lb)
Brake hose joint bracket bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Lower bracket cover bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Windshield drive unit bracket and
frame nut
M10 2 32 Nm (3.2 m·kg, 23 ft·lb)
Electrical components board nut M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Windshield bracket and wind-
shield drive unit bolt
M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rearview mirror nut M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Windshield drive unit nut M6 9 10 Nm (1.0 m·kg, 7.2 ft·lb)
Windshield drive unit bracket and
electrical components tray brack-
et bolt
M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Relay bracket bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Side cover bolt M6 3 7 Nm (0.7 m·kg, 5.1 ft·lb)
Grab bar bolt M8 5 21 Nm (2.1 m·kg, 15 ft·lb)
Center rear cowling bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Fuel pump bolt M5 6 4 Nm (0.4 m·kg, 2.9 ft·lb)
Front fuel tank bracket and frame
bolt
M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Fuel tank and front fuel tank
bracket bolt
M8 2 16 Nm (1.6 m·kg, 11 ft·lb)
Fuel tank and rear upper fuel
tank bracket bolt
M8 2 16 Nm (1.6 m·kg, 11 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
