TIGHTENING TORQUES
2-24
Rear upper fuel tank bracket and
rear lower fuel tank bracket nut
M8 1 16 Nm (1.6 m·kg, 11 ft·lb)
Rear lower fuel tank bracket and
frame bolt
M6 4 8 Nm (0.8 m·kg, 5.8 ft·lb)
Fuel tank cap bolt M5 3 6 Nm (0.6 m·kg, 4.3 ft·lb)
Storage compartment bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
T-bar bolt M10 3 37 Nm (3.7 m·kg, 27 ft·lb)
Rear fender bolt M6 4 7 Nm (0.7 m·kg, 5.1 ft·lb)
Seat lock cable assembly nut M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front wheel axle bolt M14 1 91 Nm (9.1 m·kg, 66 ft·lb)
Front wheel axle pinch bolt M8 4 See TIP.
Front brake disc bolt M6 12 18 Nm (1.8 m·kg, 13 ft·lb)
Front wheel sensor bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front wheel sensor rotor bolt M5 3 8 Nm (0.8 m·kg, 5.8 ft·lb)
Rear wheel axle nut M18 1 125 Nm (12.5 m·kg, 90 ft·lb)
Rear wheel axle pinch bolt M8 1 23 Nm (2.3 m·kg, 17 ft·lb)
Rear brake disc bolt M6 6 18 Nm (1.8 m·kg, 13 ft·lb)
Rear wheel sensor bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear wheel sensor rotor bolt M5 3 8 Nm (0.8 m·kg, 5.8 ft·lb)
Brake torque rod nut M8 2 30 Nm (3.0 m·kg, 22 ft·lb)
Rear wheel dust cover screw M5 3 5 Nm (0.5 m·kg, 3.6 ft·lb)
Rear wheel bearing retainer M56 1 80 Nm (8.0 m·kg, 58 ft·lb)
Left-hand
thread.
Brake pipe union bolt M10 4 30 Nm (3.0 m·kg, 22 ft·lb)
Brake hose union bolt M10 7 30 Nm (3.0 m·kg, 22 ft·lb)
Brake pipe flare nut M10 5 16 Nm (1.6 m·kg, 11 ft·lb)
Brake pipe/joint assembly flare
nut
M10 3 16 Nm (1.6 m·kg, 11 ft·lb)
Brake pipe/joint assembly bolt M6 3 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front brake caliper bolt M10 4 40 Nm (4.0 m·kg, 29 ft·lb)
Front brake hose holder bolt M6 3 7 Nm (0.7 m·kg, 5.1 ft·lb)
Front brake hose joint bolt M6 1 See TIP.
Front brake caliper bleed screw M8 3 6 Nm (0.6 m·kg, 4.3 ft·lb)
Front brake pad bolt M10 4 17 Nm (1.7 m·kg, 12 ft·lb)
Rear brake caliper bolt M10 2 27 Nm (2.7 m·kg, 19 ft·lb)
Rear brake hose and rear wheel
sensor lead holder bolt
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear brake hose holder bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Rear brake caliper bleed screw M7 1 6 Nm (0.6 m·kg, 4.3 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
LT
LT
LT
LT
