TIGHTENING TORQUES
2-25
Hydraulic unit assembly cap nut M8 3 16 Nm (1.6 m·kg, 11 ft·lb)
Hydraulic unit assembly bracket
and hydraulic unit assembly bolt
M6 5 7 Nm (0.7 m·kg, 5.1 ft·lb)
Metering valve bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Proportioning valve bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Sidestand nut M10 1 58 Nm (5.8 m·kg, 42 ft·lb)
Sidestand switch screw M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Centerstand nut M10 4 55 Nm (5.5 m·kg, 40 ft·lb)
Centerstand bracket nut M10 2 55 Nm (5.5 m·kg, 40 ft·lb)
Brake pedal pinch bolt M6 1 8 Nm (0.8 m·kg, 5.8 ft·lb)
Right footrest assembly bolt M8 2 28 Nm (2.8 m·kg, 20 ft·lb)
Rear brake master cylinder bolt M8 2 18 Nm (1.8 m·kg, 13 ft·lb)
Rear brake master cylinder lock-
nut
M8 1 16 Nm (1.6 m·kg, 11 ft·lb)
Left footrest assembly bolt M8 2 28 Nm (2.8 m·kg, 20 ft·lb)
Left footrest assembly bolt M10 1 49 Nm (4.9 m·kg, 35 ft·lb)
Left footrest assembly and side-
stand bolt
M10 2 65 Nm (6.5 m·kg, 47 ft·lb)
Passenger footrest and muffler
bracket bolt
M8 4 28 Nm (2.8 m·kg, 20 ft·lb)
Shift arm pinch bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Shift rod locknut M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Drive shaft dust cover bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Final gear oil drain bolt M14 1 23 Nm (2.3 m·kg, 17 ft·lb)
Final gear oil filler bolt M14 1 23 Nm (2.3 m·kg, 17 ft·lb)
Final drive assembly nut M10 4 42 Nm (4.2 m·kg, 30 ft·lb)
Final drive pinion gear bearing
retainer
M65 1 110 Nm (11.0 m·kg, 80 ft·lb)
Left-hand
thread
Coupling gear nut M16 1 110 Nm (11.0 m·kg, 80 ft·lb) Stake
Ring gear bearing housing bolt M10 2 40 Nm (4.0 m·kg, 29 ft·lb)
Ring gear bearing housing nut M8 6 23 Nm (2.3 m·kg, 17 ft·lb)
Final gear case stud bolt M8 6 9 Nm (0.9 m·kg, 6.5 ft·lb)
Ring gear bearing housing stop-
per bolt
M10 1 9 Nm (0.9 m·kg, 6.5 ft·lb)
Left-hand
thread
ECU cover bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Electrical components tray bolt M6 4 10 Nm (1.0 m·kg, 7.2 ft·lb)
Battery holder bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Air guide bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Horn bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
