REAR WHEEL
4-37
7. Install:
• Rear wheel sensor
NOTICE
ECA1MC1030
To route the rear wheel sensor lead, refer to
“CABLE ROUTING” on page 2-47.
TIP
When installing the rear wheel sensor, check the
rear wheel sensor lead for twists and the sensor
electrode for foreign materials.
8. Check:
• Rear wheel sensor installation
Check if the wheel sensor housing is installed
properly.
Distance “a” (between the wheel
sensor rotor and wheel sensor
housing)
28.84–29.64 mm (1.135–1.167 in)
T
R
.
.
Rear wheel sensor bolt
7 Nm (0.7 m·kg, 5.1 ft·lb)
a
2
1
