Yamaha FJR1300A(D) - Page 272

STEERING HEAD
4-95
11 Upper ring nut 1
12 Rubber washer 1
13 Lower ring nut 1
14 Lower bracket 1
15 Upper bearing cover 1
16 Upper bearing inner race 1
17 Upper bearing 1
18 Lower bearing 1
19 Lower bearing inner race 1
20 Dust seal 1
21 Upper bearing outer race 1
22 Lower bearing outer race 1
For installation, reverse the removal proce-
dure.
Removing the lower bracket
Order Job/Parts to remove Q’ty Remarks
LS
LS
14
18
6
5
12
LS
LTLT
LT
7
8
9
22
21
3
1
2
2
17
16
15
13
11
10
4
4
19
20
T
R
.
.
1st 52 Nm (5.2 m
•
kg, 37 ft
•
lb)
2nd 18 Nm (1.8 m
•
kg, 13 ft
•
lb)
T
R
.
.
115 Nm (11.5 m
•
kg, 85 ft
•
lb)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
.R.
