Yamaha FJR1300A(D) - Page 282

SWINGARM
4-105
3. Tighten:
• Pivot shaft
• Pivot shaft nut
• Pivot shaft self-lock nut
3. Swingarm
4. Connecting arm
A. Left side
B. Right side
T
R
.
.
Pivot shaft
23 Nm (2.3 m·kg, 17 ft·lb)
T
R
.
.
Pivot shaft nut
115 Nm (11.5 m·kg, 85 ft·lb)
T
R
.
.
Pivot shaft self-lock nut
125 Nm (12.5 m·kg, 90 ft·lb)
1
3
a
A
3
2
b
2
A
B
b
4
4
