Yamaha FJR1300A(D) - Page 307

ENGINE REMOVAL
5-6
Removing the engine
Order Job/Parts to remove Q’ty Remarks
TIP
Place a suitable stand under the engine.
1 Brake pedal 1
2 Engine bracket and engine bolt (left rear side) 2
3 Engine bracket and frame bolt (left rear side) 1
4 Engine bracket (left rear side) 1
5 Engine bracket and frame bolt (top) 4
6 Engine bracket and engine bolt (top) 2
7 Engine bracket (top) 2
8 Pinch bolt (rear lower side) 2
9 Pinch bolt (front side) 2
10 Engine mounting bolt (right front lower side) 1
11 Spacer 2
12 Engine mounting bolt (right front upper side) 1
13 Engine mounting bolt (left front lower side) 1
14 Engine mounting bolt (left front upper side) 1
15 Engine mounting nut (rear upper side) 1
T
R
.
.
32 Nm (3.2 m
•
kg, 23 ft
•
Ib)
T
R
.
.
16 Nm (1.6 m
•
kg, 11 ft
•
Ib)
T
R
.
.
18 Nm (1.8 m
•
kg, 13 ft
•
Ib)
T
R
.
.
37 Nm (3.7 m
•
kg, 27 ft
•
Ib)
T
R
.
.
37 Nm (3.7 m
•
kg, 27 ft
•
Ib)
T
R
.
.
45 Nm (4.5 m
•
kg, 32 ft
•
Ib)
T
R
.
.
45 Nm (4.5 m
•
kg, 32 ft
•
Ib)
T
R
.
.
49 Nm (4.9 m
•
kg, 35 ft
•
Ib)
T
R
.
.
49 Nm (4.9 m
•
kg, 35 ft
•
Ib)
T
R
.
.
49 Nm (4.9 m
•
kg, 35 ft
•
Ib)
T
R
.
.
24 Nm (2.4 m
•
kg, 17 ft
•
Ib)
T
R
.
.
24 Nm (2.4 m
•
kg, 17 ft
•
Ib)
T
R
.
.
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
E
E
9
9
15
11
1
11
12
17
10
6
7
16
5
5
18
2
3
4
7
6
13
19
14
20
8
