FUEL INJECTION SYSTEM
8-45
1 Condition of intake air pres-
sure sensor hose.
Check the intake air pressure
sensor hose condition.
Clogged or detached hose
→ Repair or replace the sen-
sor hose.
Start the engine and let it idle
for approximately 5 seconds.
Fault code number is not dis-
played → Service is finished.
Fault code number is dis-
played → Go to item 2.
2 Defective intake air pressure
sensor.
Execute the diagnostic
mode. (Code No. 03)
When engine is stopped:
Atmospheric pressure at the
current altitude and weather
conditions is indicated.
At sea level: Approx. 101 kPa
(757.6 mmHg, 29.8 inHg)
1000 m (3300 ft) above sea
level: Approx. 90 kPa (675.1
mmHg, 26.6 inHg)
2000 m (6700 ft) above sea
level: Approx. 80 kPa (600.0
mmHg, 23.6 inHg)
3000 m (9800 ft) above sea
level: Approx. 70 kPa (525.0
mmHg, 20.7 inHg)
When engine is cranking:
Make sure that the indication
value changes.
The value does not change
when engine is cranking. →
Check the intake air pressure
sensor.
Replace if defective.
Refer to “CHECKING THE
INTAKE AIR PRESSURE
SENSOR” on page 8-189.
Fault code No. 15
Item Throttle position sensor: open or short circuit detected.
Fail-safe system
Able/Unable to start engine
Able/Unable to drive vehicle
Diagnostic code No. 01, 13
01
Meter display
Throttle position sensor signal 1
• 12–21 (fully closed position)
• 97–106 (fully open position)
Procedure
• Check with throttle valves fully closed.
• Check with throttle valves fully open.
Fault code No. 14
Item
Intake air pressure sensor: hose system malfunction (clogged
or detached hose).
