[A]
[C-2]
[B-4]
[B-2]
[B-1]
[B-3]
•
•
•
[C-1]
•
Comes on
Fails to come on
Flashes
No
No
Push the cruise control
power switch, and check
the cruise control system
indicator light.
Fault code number is
not displayed.
Explain the conditions for
automatically deactivating the
cruise control system to the
customer.
Finished.
Is there automatic
deactivation history for the
cruise control system?
Check the malfunction
history using the multi-
function meter unit.
Is there any malfunction
history?
Diagnosis using the fault
codes.
Diagnosis using the
malfunction history codes.
Yes
Yes
OK
The cruise control power switch is
defective.
The cruise control system fuse is
blown.
The ECU is defective.
Delete the fault codes.
Final check.
Return to [A].
Return to [A].
If the engine trouble warning
light is on, diagnose the
malfunction using the fault
code that is displayed in the
multi-function meter right
display.
Refer to “TROUBLESHOOTING
DETAILS”.
