CRUISE CONTROL SYSTEM
8-96
Fault code No. 91
Item
A
Cruise control setting switch “RES+”: open or short circuit
is detected.
B
Cruise control setting switch “SET–”: open or short circuit is de-
tected.
Fail-safe system
Able to start engine
Able to drive vehicle
Diagnostic code No. 80, 81
Meter display
“ON” (when the switch is pushed)
“OFF” (when the switch is released)
Procedure
Push and release the “RES+” side of the cruise control setting
switch.
Item
Probable cause of mal-
function and check
Maintenance job
Confirmation of service
completion
1 Locate the malfunction. Execute the diagnostic
mode. (Code 80)
When the cruise control set-
ting switch “RES+” is
pushed: “ON”
When the cruise control set-
ting switch is released:
“OFF”
Malfunction → Go to item 2.
Execute the diagnostic
mode. (Code 81)
When the cruise control set-
ting switch “SET–” is pushed:
“ON”
When the cruise control set-
ting switch is released:
“OFF”
Malfunction → Go to item 2
in section B for the cruise
control setting switch “SET–”.
2 Connection of left handlebar
switch coupler.
Check the locking condition
of the coupler.
Disconnect the coupler and
check the pins (bent or bro-
ken terminals and locking
condition of the pins).
Improperly connected →
Connect the coupler secure-
ly or replace the wire har-
ness.
Turn the main switch to “ON”.
Push and release the
“RES+” side of the cruise
control setting switch.
Fault code number is not dis-
played → Service is finished.
Fault code number is dis-
played → Go to item 3.
3 Connection of main switch
coupler.
Check the locking condition
of the coupler.
Disconnect the coupler and
check the pins (bent or bro-
ken terminals and locking
condition of the pins).
Improperly connected →
Connect the coupler secure-
ly or replace the wire har-
ness.
Turn the main switch to “ON”.
Push and release the
“RES+” side of the cruise
control setting switch.
Fault code number is not dis-
played → Service is finished.
Fault code number is dis-
played → Go to item 4.
