ABS (ANTI-LOCK BRAKE SYSTEM)
8-143
3 Defective wheel sensor. If the above items were performed and no malfunc-
tions were found, connect the ABS ECU coupler
and front wheel sensor coupler, and then delete
the fault codes. If fault code number “ABS_15”
could not be deleted, the front wheel sensor is de-
fective. Replace the front wheel sensor.
Before deleting the fault codes, record all of the
fault codes and perform the related checks and
maintenance.
Fault code No. ABS_16 Symptom No continuity in the rear wheel sensor circuit.
Order Item/components and probable
cause
Check or maintenance job
1 Connections
• Rear wheel sensor coupler
• ABS ECU coupler
• Check the coupler for any pins that may be pulled
out.
• Check the locking condition of the coupler.
• If there is a malfunction, replace the wire harness
and connect the coupler securely.
Turn the main switch to “OFF” before disconnecting
or connecting a coupler.
Fault code No. ABS_15 Symptom No continuity in the front wheel sensor circuit.
Order Item/components and probable
cause
Check or maintenance job
To Next Page
