ELECTRICAL COMPONENTS
8-173
Checking the condition of the bulb sockets
The following procedure applies to all of the bulb
sockets.
1. Check:
• Bulb socket (for continuity)
(with the pocket tester)
No continuity → Replace.
Check each bulb socket for continuity in the
same manner as described in the bulb section;
however, note the following.
▼▼▼▼ ▼ ▼▼▼▼▼▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼▼▼▼
a. Install a good bulb into the bulb socket.
b. Connect the pocket tester probes to the re-
spective leads of the bulb socket.
c. Check the bulb socket for continuity. If any of
the readings indicate no continuity, replace
the bulb socket.
▲▲▲▲ ▲ ▲▲▲▲▲▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲▲▲▲
EAS28000
CHECKING THE FUSES
The following procedure applies to all of the fus-
es.
EC3P61003
To avoid a short circuit, always turn the main
switch to “OFF” when checking or replacing
a fuse.
1. Remove:
• Right upper inner panel
Refer to “GENERAL CHASSIS” on page 4-1.
2. Check:
•Fuse
▼▼▼▼ ▼ ▼▼▼▼▼▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼▼▼▼
a. Connect the pocket tester to the fuse and
check the continuity.
Set the pocket tester selector to “Ω × 1”.
b. If the pocket tester indicates “∞”, replace the
fuse.
▲▲▲▲ ▲ ▲▲▲▲▲▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲▲▲▲
3. Replace:
•Blown fuse
▼▼▼▼ ▼ ▼▼▼▼▼▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼▼▼
a. Turn the main switch to “OFF”.
b. Install a new fuse of the correct amperage
rating.
c. Set on the switches to verify if the electrical
circuit is operational.
d. If the fuse immediately blows again, check
the electrical circuit.
EWA13310
Never use a fuse with an amperage rating
other than that specified. Improvising or us-
ing a fuse with the wrong amperage rating
may cause extensive damage to the electri-
Pocket tester
90890-03112
Analog pocket tester
YU-03112-C
Pocket tester
90890-03112
Analog pocket tester
YU-03112-C
Fuses
Amperage
rating
Q’ty
Main 50 A 1
ABS motor 30 A 1
Cooling system 30 A 1
Headlight 25 A 1
ABS solenoid 20 A 1
Ignition 20 A 1
Windshield drive system 20 A 1
Fuel injection system 15 A 1
Signaling system 10 A 1
Left radiator fan motor 10 A 1
Right radiator fan motor 10 A 1
Electric throttle valve 7.5 A 1
Hazard lighting 7.5 A 1
ABS ECU 7.5 A 1
Backup 7.5 A 1
Auxiliary DC jack 3 A 1
Cruise control system 1 A 1
Brake light 1 A 1
Spare 30 A 2
Spare 25 A 1
Spare 20 A 1
Spare 15 A 1
Spare 10 A 1
Spare 7.5 A 1
Spare 3 A 1
Spare 1 A 1
