ELECTRICAL COMPONENTS
8-178
Relay unit (fuel pump relay)
Headlight relay (on/off)
Headlight relay (dimmer)
First step:
Second step:
1. Positive battery terminal
2. Negative battery terminal
3. Positive tester probe
4. Negative tester probe
Result
Continuity
(between “3” and “4”)
1. Positive battery terminal
2. Negative battery terminal
3. Positive tester probe
4. Negative tester probe
Result
Continuity
(between “3” and “4”)
B/Y
Br/W
+
R/Y
G/L
R/W
Y
/
W
1
2
3
4
1. Positive tester probe
2. Negative tester probe
3. Negative tester probe
Result
Continuity
(between “1” and “2”)
No continuity
(between “1” and “3”)
1. Positive battery terminal
2. Negative battery terminal
3. Positive tester probe
4. Negative tester probe
5. Negative tester probe
Result
No continuity
(between “3” and “4”)
Continuity
(between “3” and “5”)
G
/L
Y
L/
B
B
1
3
2
G
+
G
/L
Y
L/
B
B
1
2
3
5
4
G
