Yamaha FJR1300A(D) - Page 655

SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
9-12
36 Injector #1 Actuates the injector #1
five times at one-second
intervals.
Illuminates the engine
trouble warning light.
Check that injector #1 is
actuated five times by lis-
tening for the operating
sound.
37 Injector #2 Actuates the injector #2
five times at one-second
intervals.
Illuminates the engine
trouble warning light.
Check that injector #2 is
actuated five times by lis-
tening for the operating
sound.
38 Injector #3 Actuates the injector #3
five times at one-second
intervals.
Illuminates the engine
trouble warning light.
Check that injector #3 is
actuated five times by lis-
tening for the operating
sound.
39 Injector #4 Actuates the injector #4
five times at one-second
intervals.
Illuminates the engine
trouble warning light.
Check that injector #4 is
actuated five times by lis-
tening for the operating
sound.
48 Air induction system sole-
noid
Actuates the air induction
system solenoid five times
at one-second intervals.
Illuminates the engine
trouble warning light.
Check that the air induc-
tion system solenoid is ac-
tuated five times by
listening for the operating
sound.
50 Relay unit Actuates the relay unit five
times at one-second inter-
vals.
Illuminates the engine
trouble warning light.
(The engine trouble warn-
ing light is OFF when the
relay is ON, and the en-
gine trouble warning light
is ON when the relay is
OFF.)
Check that the relay unit is
actuated five times by lis-
tening for the operating
sound.
51 Radiator fan motor relay Actuates the radiator fan
motor relay five times at
five-second intervals. (2
seconds on, 3 seconds
off) Illuminates the engine
trouble warning light.
Check that the radiator fan
motor relay is actuated
five times by listening for
the operating sound.
52 Headlight relay Actuates the headlight re-
lay five times at five-sec-
ond intervals. (2 seconds
on, 3 seconds off) Illumi-
nates the engine trouble
warning light.
Check that the headlight
relay is actuated five times
by listening for the operat-
ing sound.
57 Grip warmer Turns on the grip warmers
for 2 minutes.
Check that the grip warm-
ers become warm.
Diagnostic
code No.
Item Actuation Procedure
