ENGINE SPECIFICATIONS
2-8
Shifting mechanism
Shift mechanism type Shift drum and guide bar
Shift fork guide bar bending limit 0.100 mm (0.0039 in)
Air filter
Air filter element Dry element
Fuel pump
Pump type Electrical
Maximum consumption amperage 6.0 A
Fuel injector
Model/quantity 0990/4
Resistance 12.0 Ω
Throttle body
Type/quantity 42EHDW/1
ID mark 1MC1 00
Throttle position sensor
Resistance 1.20–2.80 kΩ
Output voltage (at idle) 0.63–0.73 V
Accelerator position sensor
Resistance 1.08–2.52 kΩ
Output voltage (at idle) 0.63–0.73 V
Fuel injection sensor
Crankshaft position sensor resistance 421–569 Ω
Cylinder identification sensor output voltage (ON) More than 4.8 V
Cylinder identification sensor output voltage (OFF) Less than 0.8 V
Intake air pressure sensor output voltage 3.57–3.71 V
Atmospheric pressure sensor output voltage 3.57–3.71 V
Air temperature sensor resistance 5.4–6.6 kΩ at 0 °C (32.0 °F)
290–390 Ω at 80.0 °C (176.0 °F)
Coolant temperature sensor resistance 2.32–2.59 kΩ at 20.0 °C (68.0 °F)
310–326 Ω at 80.0 °C (176.0 °F)
Idling condition
Engine idling speed 1000–1100 r/min
Intake vacuum 33.3 kPa (250 mmHg, 9.8 inHg)
Water temperature 90.0–110.0 °C (194.0–230.0 °F)
Oil temperature 75.0–95.0 °C (167.0–203.0 °F)
Fuel line pressure (at idle) 300.0–390.0 kPa (3.00–3.90 kgf/cm², 43.5–56.6
psi)
Throttle grip free play 3.0–5.0 mm (0.12–0.20 in)
Air induction system
Solenoid resistance 20–24 Ω
Shaft drive
Middle gear backlash 0.10–0.20 mm (0.0039–0.0079 in)
