ELECTRICAL SPECIFICATIONS
SPEC
Item Standard Limit
Indicator light
(voltage/wattage quantity)
Neutral indicator light
High beam indicator light
Oil level indicator light
Turn signal indicator light
Fuel level warning light
Coolant temparture indicator light
Engine trouble warning light
Shift timing indicator light
LED 1
LED 1
LED 1
LED 2
LED 1
LED 1
LED 1
LED 1
SSS
SSS
SSS
SSS
SSS
SSS
SSS
SSS
Electric starting system
System type
Starter motor
Model (manufacturer)
Power output
Brushes
Overall length
Spring force
Armature coil resistance
Commutator diameter
Mica undercut
Constant mesh
SM-14 (MITSUBA)
0.6 kW
10 mm (0.39 in)
7.16 X 9.52 N (730 X 971 g,
25.77 X 34.27 oz)
0.0012 X 0.0022 Ω at 20_C (68_F)
28 mm (1.1 in)
0.7 mm (0.03 in)
SSS
SSS
SSS
3.5 mm
(0.14 in)
SSS
SSS
27 mm
(1.06 in)
SSS
Starter relay
Model (manufacturer)
Amperage
Coil resistance
2768088-A (JIDECO)
180 A
4.18 X 4.62 Ω at 20_C (68_F)
SSS
SSS
SSS
Horn
Horn type
Model (manufacturer) quantity
Max. amperage
Performance
Coil resistance
Plain
YF-12 (NIKKO) 1
3 A
105 X 113 db/2 m
1.15 X 1.25 Ω at 20_C (68_F)
SSS
SSS
SSS
SSS
SSS
Turn signal relay
Relay type
Model (manufacturer)
Self-cancelling device built-in
Turn signal blinking frequency
Wattage
Full transistor
FE246BH (DENSO)
No
75 X 95 cycles/min.
21 W 2 + 3.4 W
SSS
SSS
SSS
SSS
SSS
Oil level switch
Model (manufacturer)
5SL (SOMIC ISHIKAWA) SSS
