ELECTRICAL SPECIFICATIONS
SPEC
Item Standard Limit
Fuses (amperage quantity)
Main fuse
Fuel injection system fuse
Headlight fuse
Signaling system fuse
Ignition fuse
Radiator fan motor fuse
Backup fuse (odometer and clock)
Reserve fuse
40 A 1
15 A 1
20 A 1
15 A 1
15 A 1
15 A 1
10 A 1
40 A, 20 A, 15 A, 10 A 1
SSS
SSS
SSS
SSS
SSS
SSS
SSS
SSS
Fuel level sender
Model (manufacture)
Sender unit resistance-full
5PW (DENSO)
750 X 1,100 Ω
SSS
SSS
Starting circuit at-off relay
Model (manufacture)
Coil resistance
G8R-30Y-R (OMRON)
162 X 198 Ω
SSS
SSS
Headlight relay, Radiator fan motor
relay
Model (manufacture)
Coil resistance
ACA12115 (MATSUSHITA)
72 X 88 Ω
SSS
SSS
Fuel injection system relay
Model (manufacture)
Coil resistance
G8R-30Y-R (OMRON)
162 X 198 Ω
SSS
SSS
Water temperature sensor
Model (manufacture)
Resistance
K003T20191 (MITSUBISHI)
0.2898 X 0.3542 Ω at 80_C (176_F)
SSS
SSS
