Order Job/Part Q’ty Remarks
1
2
3
4
5
Removing the clutch cover
Bottom cowling
Right side cowling
Engine oil
Coolant
Coolant hose
Clutch cable
Clutch cover
Clutch cover gasket
Dowel pin
1
1
1
1
2
Removing the parts in the order listed.
Drain.
Refer to “CHANGING THE ENGINE OIL”
in chapter 3.
Drain.
Refer to “CHANGING THE COOLANT” in
chapter 3.
Disconnect.
Disconnect.
For installation, reverse the removal
procedure.
Refer to “COWLINGS” in chapter 3.
12 Nm (1.2 mSkg, 8.7 ftSlb)
12 Nm (1.2 mSkg, 8.7 ftSlb)
CLUTCH
ENG
EAS00273
CLUTCH
CLUTCH COVER
