WATER PUMP
COOL
12 Nm (1.2 mSkg, 8.7 ftSlb)
NOTE:
NOTE:
INSTALLING THE WATER PUMP
1. Install:
S water pump assembly
Align the projection
a
at the oil pump shaft and
water pump shaft groove
b
.
2. Install:
S water pump outlet hose
1
S water pump inlet hose
2
S Install the inlet hose with yellow
a
mark posi-
tioned outside.
S Install the hose clamp with its screw head
pointed to the inner side not to contact with the
cowling.
3. Fill:
S coolant
Refer to “CHANGING THE COOLANT” in
chapter 3.
