YASKAWA SGD7S series User Manual

1.3 Part Names
1
Basic Information on SERVOPACKs
1-5
Panel Display
Used to display SERVOPACK status, alarm numbers, and
parameters.
page 13-3
Panel Operator Keys Used to set parameters.
Panel Operator −
Analog Monitor Connector
(CN5)
You can use a special cable (peripheral device) to monitor
the motor speed, torque reference, or other values.
page 4-50
Continued from previous page.
No. Name Description Reference
18
19
20
21

YASKAWA SGD7S series Specifications

General

Series	SGD7S
Safety	STO (Safe Torque Off)
Humidity	90% RH or less (non-condensing)
Control Method	PWM Control
Communication	EtherCAT, MECHATROLINK-III, MECHATROLINK-II
Output Power	0.1 kW to 15 kW
Feedback System	Incremental encoder, Absolute encoder
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Overheating, Encoder Error
Ambient Temperature	0 to 55°C
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s²
Installation	Panel mounted
Certifications	CE, UL, cUL
