2.1 Ratings and Specifications
2.1.4 Specifications
2-9
Operating
Methods
Reference
Method
Opera-
tion
Specifi-
cations
Positioning via DeviceNet communications.
Refer-
ence
Inputs
DeviceNet communications
Commands: Movement references (positioning or speed) and origin
returns
Position
Control
Functions
Acceler-
ation/
Deceler-
ation
Methods
Linear, asymmetrical, exponential, and S-curve acceleration/decelera-
tion
Operat-
ing
Methods
Simple positioning, origin returns, continuous operation, and switching
to positioning
Fully-
Closed
Loop
Control
Supported.
Built-in
Functions
Position
Data
Latching
Position data can be latched on phase C, the origin signal, or an exter-
nal signal.
DeviceNet
Communi-
cations
Commu-
nica-
tions
Methods
DeviceNet I/O communications and explicit messages
Topology
Multidrop or T-branching
*2
Baud
Rate
125 kbps, 250 kbps, or 500 kbps (Set on rotary switch (DR).)
Cables
Special cables
(OMRON DCA1-5CN02F1 Cable with Connectors or the equivalent.)
Maxi-
mum
Number
of Nodes
64 nodes (including the master, Maximum number of slaves: 63)
Node
Address
Setting
0 to 63 (Set on NA x10 and x1 rotary switches.)
Analog Monitor (CN5)
Number of points: 2
Output voltage range: ±10 VDC (effective linearity range: ±8 V)
Resolution: 16 bits
Accuracy: ±20 mV (Typ)
Maximum output current: ±10 mA
Settling time (±1%): 1.2 ms (Typ)
Dynamic Brake (DB)
Activated when a servo alarm or overtravel (OT) occurs, or when the
power supply to the main circuit or servo is OFF.
Regenerative Processing
Built-in (An external resistor must be connected to the SGD7S-470A to
-780A.)
Refer to the following manuals for details.
Σ-7-Series Peripheral Device Selection Manual
(Manual No.: SIEP S800001 32)
Overtravel (OT) Prevention
Stopping with a dynamic brake (DB), coasting to a stop, performing a
hard stop, or smooth stop (decelerating to a stop) for a CCW-OT (CCW
Drive Prohibit Input) signal or CW-OT (CW Drive Prohibit Input) signal.
Protective Functions Overcurrent, overvoltage, low voltage, overload, regeneration error, etc.
Utility Functions Gain adjustment, alarm history, jogging, origin search, etc.
