1.2 General Description
YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual 25
Receiving
1
1.2 General Description
u T1000A Model Selection
Table 1.1 gives a reference for drive selection depending on the motor power and Normal or Heavy Duty rating.
Note: The models and capacities in shown here are based on standard settings and operation conditions. Derating is required for higher
carrier frequencies and higher ambient temperatures.
Table 1.1 T1000A Models
Note: Current derating is required when setting the carrier frequency higher. Refer to Carrier Frequency Derating on page 359 for
details.
Motor Power
(kW)
3-Phase 200 V Class 3-Phase 400 V Class
Heavy Duty Rating Normal Duty Rating Heavy Duty Rating Normal Duty Rating
Model CIMR-T
Rated Output
Current (A)
Model CIMR-T
Rated Output
Current (A)
<3>
Model CIMR-T
Rated Output
Current (A)
Model CIMR-T
Rated Output
Current (A)
<3>
0.55
<1> These values assume the carrier frequency is not set higher than 8 kHz.
<2> These values assume the carrier frequency is not set higher than 5 kHz.
<3> These values assume the carrier frequency is set to 2 kHz.
2A0004 3.2 <1> – – 4A0002 1.8 <1> ––
0.75 – – 2A0004 3.5 4A0004 3.4 <1> 4A0002 2.1
1.1 2A0006 5 <1> 2A0006 6 – – – –
1.5 2A0010 8 <1> – – 4A0005 4.8 <1> 4A0004 4.1
2.2 2A0012 11 <1> 2A0010 9.6 4A0007 5.5 <1> 4A0005 5.4
3.0 – – 2A0012 12 4A0009 7.2 <1> 4A0007 6.9
4.0 2A0021 17.5 <1> – – 4A0011 9.2 <1> 4A0009 8.8
5.5 2A0030 25 <1> 2A0021 21 4A0018 14.8 <1> 4A0011 11.1
7.5 2A0040 33 <1> 2A0030 30 4A0023 18 <1> 4A0018 17.5
11 2A0056 47 <1> 2A0040 40 4A0031 24 <1> 4A0023 23
15 2A0069 60 <1> 2A0056 56 4A0038 31 <1> 4A0031 31
18.5 2A0081 75 <1> 2A0069 69 4A0044 39 <1> 4A0038 38
22 2A0110 85 <1> 2A0081 81 4A0058 45 <1> 4A0044 44
30 2A0138 115 <1> 2A0110 110 4A0072 60 <1> 4A0058 58
37 2A0169 145 <2> 2A0138 138 4A0088 75 <1> 4A0072 72
45 2A0211 180 <2> 2A0169 169 4A0103 91 <1> 4A0088 88
55 2A0250 215 <2> 2A0211 211 4A0139 112 <2> 4A0103 103
75 2A0312 283 <2> 2A0250 250 4A0165 150 <2> 4A0139 139
90 2A0360 346 <2> 2A0312 312 4A0208 180 <2> 4A0165 165
110
2A0415 415
<2> 2A0360 360 4A0250 216 <2> 4A0208 208
– – 2A0415 415 – – – –
132 – – – – 4A0296 260 <2> 4A0250 250
160 – – – – 4A0362 304 <2> 4A0296 296
185 – – – – – – 4A0362 362
