B.6 Parameter Defaults Determined by Motor Code (E5-01)
438 YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual
u Yaskawa SST4 Series IPM Motor (For Constant Torque)
Table B.15 200 V, 1750 r/min Type Yaskawa SST4 Series Motor
No.
<1> Default setting value varies by the drive model (o2-04).
Name Unit Default Settings
E5-01
Motor Code Selection − 2202 2203 2205 2206 2208 220A 220B 220D 220E 220F 2210 2212 2213 2214 2215 2216
Voltage Class V 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18 22 30 37 45 55 75
Rated Speed r/min 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15 18.50 22.00 30.00 37.00 45.00 55.00 75.00
E5-03 Motor Rated Current A 1.77 3.54 6.56 8.96 14.79 20.94 29.58 41.1 54.2 68.2 78.6 104.2 129.2 153.1 205.2 260.4
E5-04Number of Motor Poles –6666666666666666
E5-05 Motor Stator Resistance Ω 2.247 1.132 0.774 0.479 0.242 0.275 0.161 0.111 0.071 0.049 0.040 0.030 0.020 0.013 0.009 0.006
E5-06 Motor d-Axis Inductance mH 22.32 12.38 8.90 7.39 5.06 5.82 3.86 3.59 2.67 1.98 1.69 1.31 0.88 0.77 0.55 0.40
E5-07 Motor q-Axis Inductance mH 32.50 15.72 11.96 9.63 6.42 6.74 4.66 4.32 3.10 2.41 2.12 1.61 1.14 1.04 0.69 0.50
E5-09 Motor Induction Voltage Constant 1
mVs/
rad
215.2 203.9 219.3 230.6 235.1 251.7 235.7 252.0 253.7 244.6 256.3 283.1 266.3 260.0 261.5 259.3
E5-24 Motor Induction Voltage Constant 2
mV/
(r/min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum Voltage V 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
C5-17 Motor Inertia
kgm
2
0.0016 0.0022 0.0042 0.0081 0.0133 0.013 0.017 0.027 0.044 0.054 0.063 0.113 0.137 0.252 0.30 0.41
n5-02 Motor Acceleration Time s 0.134 0.099 0.094 0.124 0.121 0.081 0.075 0.082 0.099 0.101 0.096 0.126 0.124 0.188 0.186 0.184
n8-49 d-Axis Current for High Efficiency Control % -9.3 -6.4 -10.0 -9.9 -9.7 -8.4 -11.5 -13.1 -10.9 -14.3 -15.1 -11.3 -14.1 -18.8 -11.4 -12.2
S6-02
<1>
Motor Acceleration Time s 0.134 0.099 0.094 0.124 0.121 0.081 0.075 0.082 0.099 0.101 0.096 0.126 0.124 0.188 0.186 0.184
