YASKAWA T1000A - D: References

B.3 Parameter Table
378 YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual
u d: References
Reference parameters are used to set the various frequency reference values during operation.
n
d1: Frequency Reference
n d2: Frequency Upper/Lower Limits
n d5: Torque Control
No.(Addr.)
<11> Range upper limit is determined by the maximum output frequency (E1-04) and the upper limit of the frequency reference (d2-01).
<40> When using the AOLV/PM or CLV/PM control mode, the drive will automatically set parameter o1-03 = 1 and percentage units will be used.
Name Description Setting Page
d1-01
(280H)
Frequency Reference 1
Sets the frequency reference for the drive. Setting units are determined by parameter o1-03.
Default: 0.00 Hz
Min: 0.00 Hz
Max: 400.00 Hz
<11> <40>
155
d1-02
(281H)
Frequency Reference 2 155
d1-03
(282H)
Frequency Reference 3 155
d1-04
(283H)
Frequency Reference 4 155
d1-05
(284H)
Frequency Reference 5 155
d1-06
(285H)
Frequency Reference 6 155
d1-07
(286H)
Frequency Reference 7
Sets the frequency reference for the drive. Setting units are determined by parameter o1-03.
Default: 0.00 Hz
Min: 0.00 Hz
Max: 400.00 Hz
<11> <40>
155
d1-08
(287H)
Frequency Reference 8 155
d1-17
(292H)
Jog Frequency Reference
Sets the Jog frequency reference. Setting units are determined by parameter o1-03.
Default: 6.00 Hz
Min: 0.00 Hz
Max: 400.00 Hz
<11> <40>
155
No.(Addr.) Name Description Setting Page
d2-01
(289H)
Frequency Reference Upper Limit
Sets the frequency reference upper limit as a percentage of the maximum output frequency.
Default: 100.0%
Min: 0.0%
Max: 110.0%
157
d2-02
(28AH)
Frequency Reference Lower Limit
Sets the frequency reference lower limit as a percentage of the maximum output frequency.
Default: 0.0%
Min: 0.0%
Max: 110.0%
157
d2-03
(293H)
Master Speed Reference Lower
Limit
Sets the lower limit for frequency references from analog inputs as a percentage of the
maximum output frequency.
Default: 0.0%
Min: 0.0
Max: 110.0%
157
d2-04
(2A8H)
Frequency Reference 2 Upper
Limit
Sets the frequency reference 2 upper limit as a percentage of maximum output frequency.
Default: 100.0%
Min: 0.0%
Max: 110.0%
157
d2-05
(2A9H)
Frequency Reference 2 Lower
Limit
Sets the frequency reference 2 lower limit as a percentage of maximum output frequency.
Default: 100.0%
Min: 0.0%
Max: 110.0%
157
No.(Addr.) Name Description Setting Page
d5-01
(29AH)
Torque Control Selection
0: Speed Control
1: Torque Control
Set to 0 when using a digital input to switch between Speed and Torque Control (H1- = 71).
Default: 0
Min: 0
Max: 1
160
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
