7.4 Cooling Fan and Circulation Fan
YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual 319
Periodic Inspection & Maintenance
7
7.4 Cooling Fan and Circulation Fan
NOTICE: Follow cooling fan replacement instructions. The cooling fan cannot operate properly when installed incorrectly and could
seriously damage the drive. To ensure maximum useful product life, replace all cooling fans when performing maintenance.
Contact your Yaskawa representative or the nearest Yaskawa sales office to order replacement cooling fans or circulation
fans as required.
For drives with multiple cooling fans, replace all the fans when performing maintenance to ensure maximum product
performance life.
u Number of Fans
Three-Phase 200 V Class Three-Phase 400 V Class
Model
CIMR-T
Cooling Fan Circulation Fan Page
Model
CIMR-T
Cooling Fan Circulation Fan Page
2A0004 – –
–
4A0002 – –
–2A0006 – – 4A0004 – –
2A0010 – – 4A0005 – –
2A0012 – – 4A0007 1 –
321
2A0021 1 –
321
4A0009 1 –
2A0030 2 – 4A0011 1 –
2A0040 2 – 4A0018 2 –
2A0056 2 – 4A0023 2 –
2A0069 2 – 4A0031 2 –
2A0081 2 – 4A0038 2 –
2A0110 2 –
323
4A0044 2 –
2A0138 2 – 4A0058 2 –
323
2A0169 2 –
327
4A0072 2 –
2A0211 2 – 4A0088 2 –
325
2A0250 2 – 4A0103 2 –
2A0312 2 – 4A0139 2 –
327
2A0360 3 1 4A0165 2 –
2A0415 3 1 4A0208 2 –
4A0250 3 –
4A0296 3 –
4A0362 3 1
