YASKAWA T1000A - E3-01 (Motor 2 Control Mode) Dependent Parameters

B.4 Parameter Defaults Determined by Control Mode (A1-02)
424 YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual
u E3-01 (Motor 2 Control Mode) Dependent Parameters
Table B.4 E3-01 (Motor 2 Control Mode) Dependent Parameters and Default Values
No.
<1> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<2> Default setting is determined by the drive model (o2-04) and duty selection (C6-01).
Name Setting Range Resolution
Control Modes (E3-01)
V/f (0) V/f w/PG (1) OLV (2) CLV (3)
C3-21 Motor 2 Slip Compensation Gain 0.0 to 2.5 0.1 0.0 – 1.0 1.0
C3-22 Motor 2 Slip Compensation Primary Delay Time 0 to 10000 1 ms 2000 – 200 –
C5-21 Motor 2 ASR Proportional Gain 1 0.00 to 300.00 0.01 – 0.20 – 20.00
C5-22 Motor 2 ASR Integral Time 1 0.000 to 10.000 0.001 s – 0.200 – 0.500
C5-23 Motor 2 ASR Proportional Gain 2 0.00 to 300.00 0.01 – 0.02 – 20.00
C5-24 Motor 2 ASR Integral Time 2 0.000 to 10.000 0.001 s – 0.050 – 0.500
E3-04 Motor 2 Maximum Output Frequency 40.0 to 400.0 0.1 Hz 50.0 50.0 50.0 50.0
E3-05 Motor 2 Maximum Output Voltage <1> 0.0 to 255.0 0.1 V 200.0 200.0 200.0 200.0
E3-06 Motor 2 Base Frequency 0.0 to 400.0 0.1 Hz 50.0 50.0 50.0 50.0
E3-07 Motor 2 Mid Output Frequency 0.0 to 400.0 0.1 Hz 2.5 2.5 3.0 –
E3-08 Motor 2 Mid Output Frequency Voltage <1> 0.0 to 255.0 0.1 V
15.0 (Motor Capacity:
0.55 to 4.0 kW)
14.0 (5.5 to 45 kW)
12.0 (55 kW and above)
15.0 (Motor Capacity:
0.55 to 4.0 kW)
14.0 (5.5 to 45 kW)
12.0 (55 kW and above)
14.4 (Motor Capacity:
0.55 to 4.0 kW)
13.2 (5.5 kW and above)
–
E3-09 Motor 2 Minimum Output Frequency 0.0 to 400.0 0.1 Hz 1.3 1.3 0.5 0.0
E3-10 Motor 2 Minimum Output Voltage <1> 0.0 to 255.0 0.1 V
9.0 (Motor Capacity: 0.55
to 4.0 kW)
7.0 (5.5 to 45 kW)
6.0 (55 kW and above)
9.0 (Motor Capacity: 0.55
to 4.0 kW)
7.0 (5.5 to 45 kW)
6.0 (55 kW and above)
3.0 (Motor Capacity: 0.55
to 4.0 kW)
2.4 (5.5 kW and above)
0.0
