4.6 Auto-Tuning
YASKAWA ELECTRIC SIEP C710616 30B YASKAWA AC Drive T1000A Technical Manual 95
Start-Up Programming & Operation
4
n T2-04: PM Motor Rated Power
Specifies the motor rated power in kilowatts.
n
T2-05: PM Motor Rated Voltage
Sets the motor rated voltage.
n
T2-06: PM Motor Rated Current
Enter the motor rated current in amps.
n
T2-07: PM Motor Rated Frequency
Enter the motor rated frequency in Hz.
Note: T2-07 will be displayed when in OLV/PM.
n T2-08: Number of PM Motor Poles
Enter the number of motor poles.
n
T2-09: PM Motor Rated Speed
Enter the motor rated speed in r/min.
Note: T2-09 will be displayed when in AOLV/PM and CLV/PM.
n T2-10: PM Motor Stator Resistance
Enter the motor stator resistance per motor phase.
n
T2-11: PM Motor d-Axis Inductance
Enter the d axis inductance per motor phase.
n
T2-12: PM Motor q-Axis Inductance
Enter the q axis inductance per motor phase.
No. Name Setting Range Default
T2-04 PM Motor Rated Power 0.00 to 650.00 kW Depending on o2-04 and C6-01
No. Name Setting Range Default
<1> The setting range and default value shown here is for a 200 V class drive. These values double when using a 400 V class unit.
T2-05 PM Motor Rated Voltage 0.0 to 255.0 V 200.0 V
No. Name Setting Range Default
T2-06 PM Motor Rated Current
10% to 200% of the drive rated
current.
Depending on o2-04
No. Name Setting Range Default
T2-07 PM Motor Rated Frequency 0.0 to 400.0 Hz 87.5 Hz
No. Name Setting Range Default
T2-08 Number of PM Motor Poles 2 to 48 6
No. Name Setting Range Default
T2-09 PM Motor Rated Speed 0 to 24000 r/min 1750 r/min
No. Name Setting Range Default
T2-10 PM Motor Stator Resistance 0.000 to 65.000 Ω Depending on T2-02
No. Name Setting Range Default
T2-11 PM Motor d-Axis Inductance 0.00 to 600.00 mH Depending on T2-02
No. Name Setting Range Default
T2-12 PM Motor q-Axis Inductance 0.00 to 600.00 mH Depending on T2-02
