Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
See Terms and abbreviations (page 132).
Other [bit]
On-time 2 exceeded /
uint32
Selects the optional warning message for on-time timer 2.On-time 2 warn
message
33.24
1
A887 On-Time 2. The message text can be edited on the
control panel by choosing Menu – Settings – Edit texts.
On-time 2 exceeded
6
A88C Device clean.
Clean device
7
A890 Additional cooling fan.
Maintain additional
cooling fan
8
A88E Cabinet fan.
Maintain cabinet fan
9
A88D DC capacitor.
Maintain DC
capacitors
10
A880 Motor bearing.
Maintain motor
bearing
- / uint32Actual present value of signal edge counter 1.
The counter is incremented every time the signal selected
by parameter 33.33 Edge counter 1 source switches on or
off (or either, depending on the setting of 33.32 Edge
counter 1 function). A divisor may be applied to the count
(see 33.34 Edge counter 1 divider).
When the counter exceeds the limit set by 33.31 Edge
counter 1 warn limit, bit 2 of 33.1 Counter status is set to
1. The warning specified by 33.35 Edge counter 1 warn
message is also given if enabled by 33.32 Edge counter
1 function.
The counter can be reset from the Drive Composer PC
tool, or from the control panel by keeping Reset depressed
for over 3 seconds.
Edge counter 1 actual33.30
- / -Actual present value of signal edge counter 1.0...4294967295
- / uint32Sets the warning limit for signal edge counter 1.Edge counter 1 warn
limit
33.31
- / -Warning limit for signal edge counter 1.0...4294967295
- / uint16Configures signal edge counter 1.Edge counter 1
function
33.32
0 = Loop: When the limit is reached, the counter is reset.
The counter status (bit 2 of 33.1) switches to 1 and remains
so until the counter is again incremented. The warning (if
enabled) stays active for at least 10 seconds.
1 = Saturate: When the limit is reached, the counter status
(bit 2 of 33.1) switches to 1, and remains so until 33.30 is
reset. The warning (if enabled) also stays active until 33.30
is reset.
Counter modeb0
0 = Disable: No warning is given when the limit is reached
1 = Enable: A warning (see 33.35) is given when the limit
is reached
Warning enableb1
Count rising edges
0 = Disable: Rising edges are not counted
1 = Enable: Rising edges are counted
Count rising edgesb2
