Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
2
Bit 0 of 10.21 RO status (page 178).
RO1
See Terms and abbreviations (page 132).
Other [bit]
On-time 1 exceeded /
uint32
Selects the optional warning message for on-time timer 1.On-time 1 warn
message
33.14
0
A886 On-Time 1. The message text can be edited on the
control panel by choosing Menu – Settings – Edit texts.
On-time 1 exceeded
6
A88C Device clean.
Clean device
7
A890 Additional cooling fan.
Maintain additional
cooling fan
8
A88E Cabinet fan.
Maintain cabinet fan
9
A88D DC capacitor.
Maintain DC
capacitors
10
A880 Motor bearing.
Maintain motor
bearing
- / uint32Displays the actual present value of on-time timer 2.
The timer runs whenever the signal selected by parameter
33.23 On-time 2 source is on.
When the timer exceeds the limit set by 33.21 On-time 2
warn limit, bit 1 of 33.1 Counter status is set to 1. The
warning specified by 33.24 On-time 2 warn message is
also given if enabled by 33.22 On-time 2 function.
The timer can be reset from the Drive Composer PC tool,
or from the control panel by keeping Reset depressed for
over 3 seconds.
On-time 2 actual33.20
- / -Actual present value of on-time timer 2.0...4294967295 s
- / uint32Sets the warning limit for on-time timer 2.On-time 2 warn limit33.21
- / -Warning limit for on-time timer 2.0...4294967295 s
- / uint16Configures on-time timer 2.On-time 2 function33.22
0 = Loop: When the limit is reached, the counter is reset.
The counter status (bit 1 of 33.1) switches to 1 for one
second. The warning (if enabled) stays active for at least
10 seconds.
1 = Saturate: When the limit is reached, the counter status
(bit 1 of 33.1) switches to 1, and remains so until 33.20 is
reset. The warning (if enabled) also stays active until 33.20
is reset.
Counter modeb0
0 = Disable: No warning is given when the limit is reached
1 = Enable: A warning (see 33.24) is given when the limit
is reached
Warning enableb1
Reservedb2…15
1 = 10000h…FFFFh
False / uint32Selects the signal to be monitored by on-time timer 2.On-time 2 source33.23
0Constant 0 (timer disabled).False
1Constant 1.True
2
Bit 0 of 10.21 RO status (page 178).
RO1
346 Parameters
