Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
0 = Loop: When the limit is reached, the counter is reset.
The counter status (bit 3 of 33.1) remains 1 until the counter
is again incremented. The warning (if enabled) stays active
for at least 10 seconds.
1 = Saturate: After the limit is reached, the counter status
(bit 3 of 33.1) remains 1 until 33.40 is reset. The warning
(if enabled) also stays active until 33.40 is reset.
Counter modeb0
Warning enable
0 = Disable: No warning is given when the limit is reached
1 = Enable: A warning (see 33.45) is given when the limit
is reached
Warning enableb1
Count rising edges
0 = Disable: Rising edges are not counted
1 = Enable: Rising edges are counted
Count rising edgesb2
Count falling edges
0 = Disable: Falling edges are not counted
1 = Enable: Falling edges are counted
Count falling edgesb3
Reservedb4…15
1 = 10000h…FFFFh
False / uint32Selects the signal to be monitored by signal edge counter
2.
Edge counter 2
source
33.43
00.False
11.True
2
Bit 0 of 10.21 RO status (page 178).
RO1
See Terms and abbreviations (page 132).
Other [bit]
1 / uint32Defines a divisor for signal edge counter 2. Determines
how many signal edges increment the counter by 1.
Edge counter 2
divider
33.44
- / -Divisor for signal edge counter 2.1...4294967295
Edge counter 2
exceeded / uint32
Selects the optional warning message for signal edge
counter 2.
Edge counter 2 warn
message
33.45
3
A889 Edge counter 2. The message text can be edited on
the control panel by choosing Menu – Settings – Edit texts.
Edge counter 2
exceeded
11
A884 Main contactor.
Counted main
contactor
12
A881 Output relay.
Counted output relay
13
A882 Motor starts.
Counted motor starts
14
A883 Power ups.
Counted power ups
15
A885 DC charge.
Counted DC charges
Parameters 349
