Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Value counter 1
exceeded / uint32
Selects the optional warning message for value counter 1.Value counter 1 warn
message
33.55
4
A88A Value counter 1. The message text can be edited
on the control panel by choosing Menu – Settings – Edit
texts.
Value counter 1
exceeded
10
A880 Motor bearing.
Maintain motor
bearing
0 / real32Displays the actual present value of value counter 2.
The value of the source selected by parameter 33.63 Value
counter 2 source is read at one-second intervals and added
to the counter. A divisor can be applied to the count (see
33.64 Value counter 2 divider).
When the counter exceeds the limit set by 33.61 Value
counter 2 warn limit, bit 5 of 33.1 Counter status is set to
1.
The warning specified by 33.65 Value counter 2 warn
message is also given if enabled by 33.62 Value counter
2 function.
The counter can be reset from the Drive Composer PC
tool, or from the control panel by keeping Reset depressed
for over 3 seconds.
Value counter 2
actual
33.60
- / -Actual present value of value counter 2.-2147483008...2147483008
- / real32Sets the limit for value counter 2.
With a positive limit, bit 5 of 33.1 Counter status is set to
1 (and a warning optionally generated) when the counter
is equal or greater than the limit.
With a negative limit, bit 5 of 33.1 Counter status is set to
1 (and a warning optionally generated) when the counter
is equal or smaller than the limit.
0 = Counter disabled.
Value counter 2 warn
limit
33.61
- / -Limit for value counter 2.-2147483008...2147483008
- / uint16Configures value counter 2.Value counter 2
function
33.62
0 = Loop: When the limit is reached, the counter is reset.
The counter status (bit 5 of 33.1) switches to 1 for one
second. The warning (if enabled) stays active for at least
10 seconds.
1 = Saturate: When the limit is reached, the counter status
(bit 5 of 33.1) switches to 1, and remains so until 33.60 is
reset. The warning (if enabled) also stays active until 33.60
is reset.
Counter modeb0
Warning enable
0 = Disable: No warning is given when the limit is reached
1 = Enable: A warning (see 33.65) is given when the limit
is reached
Warning enableb1
Reservedb2…15
1 = 10000h…FFFFh
Not selected / uint32Selects the signal to be monitored by value counter 2.Value counter 2
source
33.63
Parameters 351
