2000-OSM, F1 4-8
To view the data from the second Chroma I/O Board, enter "2" in the highlighted box on the screen
and then press the F2 (Select Chroma Bd and View) soft key. The Chroma Board #2 screen will
appear (see Figure 4-8) and all screens showing Chroma I/O Board data will now show the data from
Chroma Board #2.
********** Chroma Board #2 **********
Detector: FID
Flame: Lit Ignitor: Off H2: None
Hardware Zero: 5.10mV ( 4.7%)
Software Zero: - 3.18mV
Detector Reading: 1.98mV
Ignitor: Manual Auto Auto Timeout
Timeout: 0 seconds
FPD Temp Zone: 0
Manually Manual
Exit Graphics Zero Ignitor
Baseline On
F1 F2 F3 F4
Figure 4-8. SECOND CHROMA BOARD SCREEN
Pressing the F3 (Select Chroma Bd and Exit) soft key will also change the selected board, but it will
not display the Chroma I/O Board #2 screen.
The Control Parameters screen contains the entries for selecting whether Chroma I/O Board #2 is run
as a master or a slave. To view the Control Parameters screen, press the F1 (Commands) soft key
on the Background Screen. On the Commands screen, cursor to MISC. and press the F2 (Control
