4-17 2000-OSM, F1
5. Cursor to the Calibration Type line. The current choice is underlined. To change the choice,
cursor right or left to the desired type (in this case Ext Std) and then cursor to the next line.
Moving the cursor up or down sets the new choice.
6. Cursor to each line in turn and choose the appropriate term or value:
Analysis Normalization: No
Primary Cal Stream: 10
Secondary Cal Stream: 0
Benchmark Stream: 0
Multiplier Exponent and K Factor are updated by calibration; it is not necessary to set them.
7. Review each line to ensure you have entered the correct data and then press the F1 (Continue)
soft key.
8. The Method Table #01 screen will appear (see Figure 4-16), allowing you to enter the time-
related data from Figure 4-13.
***** Method Table #01 *****
Time Function Value
[0001] Valve On One
0005 Valve Off One
0006 Stream Step N/A
0007 Auto Zero N/A
0012 Slope Detect On Now
0020 Valve On Two
0021 Valve Off Two
0030 Component One
More Below
Exit Insert Delete Cal Define
Line Line & Cycle
Time
F1 F2 F3 F4
Figure 4-16. METHOD TABLE #01 SCREEN
9. Press the F2 (Insert Line) soft key and then enter “1” using the number keys.
10. Cursor to the Function column. The number you entered now changes to “0001.” In the Function
column, use the up and down arrow keys to scroll the function names until “Valve On” appears,
and then cursor to the right.
11. In the Value column, cursor up or down until “One” appears.
12. Press the F2 (Insert Line) soft key and repeat the insertion procedure for each line in the Method
Table down through “Valve Two Off.”
13. After you complete the “Valve Two Off” line, press the F2 (Insert Line) soft key.
To Next Page
