6. Cursor to the Function field and scroll to Temp Contrl. In Figure 4-41, with Temp Contrl in the
Function field the Value column lists Two as the function to be performed from the Temperature
Control Table.
***** Method Table #01 *****
Time Function Value
[0001] Temp. Contrl Two
0010 Temp. Check One
0120 Noise Calc On
0125 Noise Calc Off
0128 Auto Zero N/A
0130 Skp, Nxt,Str= Nine
0132 Valve On One
0155 Valve Off One
More Below
Insert Delete Cal Define
Exit Line Line & Cycle
Time
F1 F2 F3 F4
Figure 4-41. METHOD TABLE #01 SCREEN
7. Move the cursor to the Value column and the Temperature Control Table appears, with the cursor
on Entry line 02 (see Figure 4-42). Note the Entry line number when you enter the table so you
can exit the table from the same line, if desired.
***** Temperature Control *****
Set Point Ramp Rate
Entry Zone C C/MIN
01 Temp Zone1 150.0 25.00
[02] Temp Zone1 250.0 50.00
03 Temp Zone1 100.0 01.00
04 Temp Zone1 0.000 0.000
05 Temp Zone1 0.000 0.000
06 Temp Zone1 0.000 0.000
07 Temp Zone1 0.000 0.000
08 Temp Zone1 0.000 0.000
More Below
Exit
F1 F2 F3 F4
Figure 4-42. TEMPERATURE CONTROL SCREEN
