ABB PGC2000 - Common DO Mask Main Screen

6-44 2000-OSM, F1
4. On the Common DO Mask, Main screen (see Figure 6-24), cursor down to the desired alarm
name and verify the selection in the right-hand column.
***** Common DO Mask, Main *****
Active Sensors: (Expand) Common DO
Component High: Common DO
Component Low: Common DO
Hardware: Common DO
Power Fail: Common DO
Idle: Common DO
Flame Out: Common DO
Clock: (Expand) Common DO
Method Function: (Expand) Common DO
More Below
Expand
Exit Mask
F1 F2 F3 F4
Figure 6-24. COMMON DO MASK MAIN SCREEN
5. To change the alarm common output, toggle the left or right cursor to obtain the desired selection
(Common DO or Masked).
6. If the selected alarm has "(Expanded)" after the alarm name, the alarm has subordinate
indicators. To view these subordinates, cursor to the desired alarm line and press the F2
(Expand Mask) soft key.
7. On the expanded alarm screen, repeat steps 4 and 5 to change a specific alarm's output.
8. Press the F2 (Exit and Update) soft key to save the new alarm data, or press the F1 (Escape) soft
key to retain the original data.
9. Press the F1 soft key as necessary to return to the Background screen.
