4-7 2000-OSM, F1
Figure 4-6). While the Background screen provides information on both detectors, other screens will
show the data from only one of the two detectors at a time.
********** B A C K G R O U N D **********
ABB Analytical GCC Remote 0.1
803V031-1R (Sim Dual Det) (C) 2001
19-JUN-2002 WED 15:52:34
Chroma 1 Chroma 2
Analysis Time: 0863/1080 0863/1076
Stream/Method: 20/01 19/02
Purging : 01 02
#Peaks/State : 10/Baseline 03/Baseline
Key Component: HEXANE + E-MERCAPT.
0.394 4.188
Exit Manual Cur Report,
to Control Basic I/O & Alarms
Commands Options
F1 F2 F3 F4
Figure 4-6. BACKGROUND SCREEN, SIMULTANEOUS DUAL DETECTORS
To select or change which detector’s data is viewed, press the F2 (Manual Control) soft key on the
Background screen. On the Manual Control Mode screen, press the F2 (Detector and Graphics) soft
key. When the Chroma Board screen appears (see Figure 4-7), the top line identifies the board
whose data is shown.
********** Chroma Board #? **********
Chroma Board #: [ 1 ]
Select Select
Escape Chroma Bd Chroma Bd
and View and Exit
F1 F2 F3 F4
Figure 4-7. FIRST CHROMA BOARD SCREEN
