2000-OSM, F1 2-27
2. On the Manual Control Mode screen (see Figure 2-16), cursor down to CHROMA, then left to
OFF.
****** Manual Control Mode ******
Valves:- - - - - - - - Time:00000
Enter Valve:
[0]
Cycle Time:00000
RECORDER: Method Tbl: 000
Offset : 0 % Stream: 01
Attn : 5 Purging: 01
Off Chroma Bar Trend Peaks: 00
PURGE SELECT: :0 State: Idle
Start Crest End Peak
Time Time Time Area Type
Last: 52 55 73 18032 Val-Bas
38 43 51 15322 Bas-Val
Exit Detector Manually Press. &
To and Zero Temp.
Background Graphics Baseline Control
F1 F2 F3 F4
Figure 2-16. MANUAL CONTROL MODE SCREEN
3. Press the ENTER key. The recorder turns off.
4. Cursor to CHROMA and then press the ENTER key. The recorder turns on and will record the
chromatogram.
5. When the chromatogram is complete, press the F1 soft key as necessary to return to the
Background screen.
Displaying a Chromatogram
1. On the Background screen press the F2 (Manual Control) soft key.
2. On the Manual Control Mode screen press the F2 (Detector and Graphics) soft key.
3. On the Chroma Board screen press the F2 (Graphics) soft key.
4. On the Graphics Mode screen press the F2 (Display the Graphics) soft key. A chromatogram will
scroll up the screen as it happens. A baseline at mid-screen is good.
5. When you have completed the chromatogram display, press the F1 soft key as necessary to
return to the Background screen.
Displaying the Percent Offset
1. On the Background screen press the F2 (Manual Control) soft key.
2. On the Manual Control Mode screen press the F3 (Manually Zero Baseline) soft key.
