2000-OSM, F1 5-11
2. On the Digital Board 1 Digital Input screen (see Figure 5-10), verify each pin and
function.
***** Digital Board 1 Digital Input *****
Pin Function Number State
TB6-1 VistaBasic #5 NO
TB6-2 VistaBasic #6 NO
TB6-3 VistaBasic #7 NO
TB6-4 VistaBasic #8 NO
TB6-5 VistaBasic #9 NO
TB6-6 VistaBasic #10 NO
TB6-7 VistaBasic #11 NO
TB6-8 VistaBasic #12 NO
More Below
Exit
F1 F2 F3 F4
Figure 5-10. DIGITAL BOARD DIGITAL INPUT SCREEN
3. If all entries are correct, press the F1 (Escape) soft key to return to the second Digital
Configuration screen. If there are any errors on this screen, correct the errors and then press the
F2 (Exit and Update) soft key to save the corrected data and return to the second Digital
Configuration screen.
Digital Board 1 Output Table
1. After you cursor to Digital Board 1 on the second Digital Configuration screen, press the F2 (Edit
The Output Table) soft key.
