5-10 2000-OSM, F1
2. On the first Chroma Board 1 Digital Output screen, cursor to VistaII and press the F1 (Continue)
soft key.
3. On the second Chroma Board 1 Digital Output screen (see Figure 5-9), verify each pin and
function.
***** Chroma Board 1 Digital Output *****
Pin Function Number State
J15A-1 Valve #1 NO
J15A-2 Valve #2 NO
J15A-3 Valve #3 NO
J15A-4 Valve #4 NO
J15A-5 Valve #5 NO
J15A-6 Valve #6 NO
J15A-7 Stream #1 NO
J15A-8 Stream #2 NO
More Below
Exit
F1 F2 F3 F4
Figure 5-9. CHROMA BOARD DIGITAL OUTPUT SCREEN #2
4. If all entries are correct, press the F1 (Escape) soft key to return to the second Digital
Configuration screen. If there are any errors on this screen, correct the errors and then press the
F2 (Exit and Update) soft key to save the corrected data and return to the second Digital
Configuration screen.
Digital Board 1 Input Table
1. After you cursor to Digital Board 1 on the second Digital Configuration screen, press the
F2 (Edit The Input Table) soft key.
