ABB PGC2000 User Manual

2-38 2000-OSM, F1
1. On the VN Menu screen with Startup highlighted, press the F4 (Refresh VNSA Tables) soft key
and then press the Escape soft key to return to the Commands screen.
2. On the Commands screen, cursor to TESTING/SETUP and then press the F4 (Status Display)
soft key.
3. On the Controller Status screen (see Figure 2-24), note that "Blocks Acked" and "Blocks
Received" both have numbers, indicating that your command to Refresh VNSA Tables was sent
and acknowledged. You are now connected to VistaNET.
***** Controller Status *****
CPU: 41% Memory: 089% / 342656 Bytes
Channel: One Two
Domain: 0.1 0.2
# Blocks Acked 001463 000955
# Blocks Not Acked 000360 000167
# Blocks Received 001467 000953
# Purges/Queued 000000 000000
# Time Outs 000372 000365
# Blocks Dropped 000000 000000
# Blocks Avail/Used 000014 000000
Clear
Escape Highway
Stats
F1 F2 F3 F4
Figure 2-24. CONTROLLER STATUS SCREEN
