R3132 Series Spectrum Analyzer Operation Manual
3.3.18 POWER MEASURE Key (Power Measurement)
3-63
Insert Inserts a column at the cursor position.
Delete Deletes a column at the cursor position.
Table Init All data is cleared from the table.
Show Result Displays the Show Result menu and displays the measurement re-
sult in full screen mode. The setup conditions and detailed results
are displayed for each frequency band.
Prev Result Displays the previous frequency band result on the screen.
Next Result Displays the next frequency band result on the screen.
Sweep Count ON/OFF Toggles the sweep count (used with the Max Hold mode, Min
Hold mode, Average function, Power Average function or Aver-
age Power measurement) on or off.
ON: Allows you to set the sweep count. A pass/fail judgment
is performed when the number of sweeps matches the
specified sweep count.
NOTE: If Trace mode is set to Write mode, it is automatically
changed as shown below according to the Detector setting
as shown below:
The Trace mode stays in Write mode if Detector mode is
set to Normal.
The Trace mode is changed to Max Hold mode if Detector
mode is set to Positive.
The Trace mode is changed to Min Hold mode if Detector
mode is set to Negative.
The Trace mode is changed to AVG mode if Detector
mode is set to Sample.
OFF: Turns the sweep count off. The Max Hold mode, Min
Hold mode, Average function, Power Average function
or Average Power measurement is turned off and a
pass/fail judgment is performed for each sweep.
PASS Judge UP/LOW Toggles the pass area between UP and LOW.
UP: The area above the limit level is set to Pass.
LOW: The area below the limit level is set to Pass.
Spurious Freq OFF Turns the spurious measurement (in frequency mode) off, and dis-
plays the Power menu.
To Next Page
