9 Maintenance of the Chip Priming Station
Cleaning the Syringe Adapter
Cleaning the Syringe Adapter
1 Open the priming station.
2 Move the mounting ring holding the adapter in place to the left as shown in
Figure 4 on page 134. The ring will come off.
Figure 4 Mounting ring of the syringe adapter
When Quarterly or whenever it is clogged.
Parts required # p/n Description
1 NA Syringe kit that comes with each DNA, RNA and Protein kit
1 NA Deionized water
6\ULQJHDGDSWHU
0RXQWLQJULQJ
