Agilent Technologies 2100 Maintenance And Troubleshooting Guide

Maintenance and Troubleshooting 137
Maintenance of the Chip Priming Station
9
Replacing the Gasket
Replacing the Gasket
The silicone gasket, see Figure 6 on page 137, ensures a tight connetion
between the chip and syringe adapter.
Figure 6 Syringe adapter with gasket
1 Remove the syringe adapter out of the chip priming station as described in
“Replacing the Syringe Adapter” on page 136.
Gasket
Syringe
adapter
When Quarterly or when it is torn.
Parts required # p/n Description
1 G2938-68716 Gasket kit
